SENSOR SECTION |
Image Sensor |
1/3.1-inch BSI MOS Sensor |
Effective Pixels |
6.03 megapixels [16:9] |
LENS SECTION |
F Value |
F1.8 ? F3.6 |
Optical Zoom |
20x |
Focal Length |
4.08 ? 81.6 mm |
35 mm Film Camera Equivalent (Motion Image/Still Image) |
29.5 ? 612 mm [16:9] |
Filter Diameter |
49 mm |
Lens Brand |
Panasonic Lens |
CAMERA SECTION |
Standard Illumination |
1400 lx |
Minimum Illumination |
1.2 lx (Super Gain 36dB, Shutter 1/25) |
Focus |
Auto / Manual |
Zoom |
Intelligent Zoom OFF |
20x |
Intelligent Zoom ON |
40x |
Digital Zoom |
2x / 5x / 10x |
White Balance |
Auto / 3200K / 5600K / VAR (2000K—15000K) / Ach Fixed / Bch Fixed |
Shutter Speed |
1/6 — 1/8000 |
Shutter Speed |
Super Slow: 1/100 — 1/8000 |
Iris |
Auto / Manual |
Image Stabilizer |
5-axis HYBRID O.I.S.+ with Level Shot Function |
|
RECORDING SECTION |
Recording Media |
SDHC/SDXC Memory Card |
Recording Format |
MOV / MP4 |
Recording Format |
AVCHD: AVCHD Progressive |
Video Compression Method |
MPEG-4 AVC/H.264 |
Audio Compression Method |
MOV: LPCM (2ch) |
Audio Compression Method |
MP4: LPCM (2ch) |
Audio Compression Method |
AVCHD: Dolby Digital (2ch) |
System Frequency |
50.00Hz |
Recording / Playback Mode |
MP4 |
1920x1080 50p 50M: Average 50Mbps (VBR), LPCM |
MP4 |
1920x1080 50i 50M: Average 50Mbps (VBR), LPCM |
MP4 |
1920x1080 25p 50M: Average 50Mbps (VBR), LPCM |
MOV |
1920x1080 50p 50M: Average 50Mbps (VBR), LPCM |
MOV |
1920x1080 50i 50M: Average 50Mbps (VBR), LPCM |
MOV |
1920x1080 25p 50M: Average 50Mbps (VBR), LPCM |
AVCHD |
PS 1080 50p: 1920x1080, Max. 28Mbps (VBR) |
AVCHD |
PH 1080 50i: 1920x1080, Max. 24Mbps (VBR) |
AVCHD |
HA 1080 50i: 1920x1080, Average 17Mbps (VBR) |
AVCHD |
HE 1080 50i: 1440x1080, Average 5Mbps (VBR) |
AVCHD |
PM 720 50p: 1280x720, Average 8Mbps (VBR) |
AVCHD |
SA 576 50i: 720x576 (SIDE CROP/SQUEEZE), Average 9Mbps (VBR) |
|
Thumbnail Display |
20 thumbnails/page, 9 thumbnails/page, 1 thumbnail/page |
Microphone |
Stereo Microphone |
Speaker |
Dynamic type |
STILL IMAGE SECTION |
Recording Format |
JPEG (DCF/Exif2.2) |
Recording Image Size |
Recording Mode: [16:9] 2.1 megapixels (1920 x 1080), 0.2 megapixels (640 x 360, [4:3] 0.3 megapixels (640 x 480) |
Recording Image Size |
Playback Mode: [16:9] 2.1 megapixels (1920 x 1080), 0.9 megapixels (1280 x 720) |
Flash |
— |
GENERAL SECTION |
Power Supply |
7.2V (Battery) / 12V (AC Adaptor) |
Power Consumption |
11.7W (Recording) / 27.4W (Charging) |
Dimensions (W x H x D) |
Approx. 170 x 170 x 335 mm (6.69 x 6.69 x 13.2 inch) |
Weight (w/o Battery and SD Card) |
Approx. 1500g (3.31 lb) |
LCD Monitor |
3.0-inch Wide LCD monitor (Approx. 460K dots) |
Viewfinder |
0.24-inch Wide EVF (Approx. 1,555K dots equivalent) |
Manual Ring |
Focus / Zoom / Iris |
Interface |
AV |
Yes |
HDMI |
Type A |
XLR Input |
XLR (3 pins) x 2 |
XLR Input |
Line:0dBu/+4dBu, Mic:-40dBu/-50dBu/-60dBu |
Headphone |
Yes (3.5mm stereo mini) |
USB |
Micro-B: USB 2.0 Hi-Speed, Mass Storage Function (read only) |
USB |
Type A: USB 2.0 Hi-Speed, for External Media Device Connection*, Bus Power Supply |
Camera Remote |
2.5mm super mini jack x 1 (ZOOM S/S) |
Camera Remote |
3.5mm mini jack x 1 (FOCUS/IRIS) |
LED Video Light |
Average Illumination |
Approx. 300 lx (1.0m) |
Irradiation Angle |
Approx. 30° |
Color Temperature |
Approx. 5000K |
Average Illumination with Diffusion Filter |
Approx. 70 lx (1.0m) |
Color Temperature with Color Conversion Filter |
Approx. 3000K |
Accessory Shoe |
Yes |
Wi-Fi |
Standard |
— |
Frequency |
— |
NFC |
— |
STANDARD ACCESSORY |
AC Adaptor |
Yes |
AC Cable |
Yes |
Rechargeable Battery Pack |
Yes (2,900mAh) |
Battery Charger |
— |
IR Remote |
— |
HDMI Cable |
— |
AV Multi Cable |
— |
AV Cable |
Yes |
Shoe adaptor |
— |
USB Cable |
— |
Microphone Holder |
Yes |
Microphone Holder Screws |
Yes (2 Screws) |
Input Terminal Cap |
Yes (2 Caps) |
Shoulder Strap |
— |
Eye Cup |
Yes |
Lens Cap |
Yes |
LED Light Filter |
Difusion Filter / Color Conversion Filter |
Editing Software |
— |
NOTE |
*External media device with a capacity of 32 GB or less, or more than 2 TB, cannot be used. |
NOTE |
Specifications are subject to change without notice. |
